Specification
| Brand | Merida |
|---|---|
| Frame | Lite Aluminium, Next Generation enduro geometry, internal cable routing, long seat post insert depth. Boost axles standard, threaded BB, trail mount and bottle bosses, flip chip for mullet or 29er. max tyre size – 2.5" |
| Rear Shock | RockShox Deluxe Select+; lockout |
| Fork | Suntour XCR34 LOR DS; Air; Boost; 140mm; Tapered; 51mm fork offset; Max. tyre size: 29" x 2.4" |
| Head Set | Merida 8158 1-1/8"-1.5" cartridge bearing |
| Stem | Merida Expert eTRII; aluminium; 35mm diameter; 0 degree rise – Stem length: 50mm (all sizes). GoPro & Supernova mount point. |
| Handle Bars | Merida Team; TR; aluminium; 780mm wide; XS/S 18mm rise; M/L/XL 30mm rise |
| Tape Grips | Merida Comp EC |
| Brakes | Tektro HD-M745; 4 piston hydraulic disc brake caliper with Tektro TR203-35; 203mm rotor |
| Brake Levers | Tektro HD-M745 |
| Rear Derailleur | Shimano Deore M5100 Shadow+ |
| Rear Hub | Shimano MT400-B; 148x12mm; 32 spokes; Center lock. With Merida Comp TR axle including removable lever, 6mm allen key |
| Front Hub | Shimano MT400-B; 110x15mm; 32 spokes; Center lock |
| Shift Levers | Shimano Deore M5100 and Shimano SL-MT500-IL dropper post lever |
| Cassette | KMC X11 |
| Chainset | Race Face Ride; 32 tooth chainset. Crank length: 170mm-S, 175mm-M up |
| Pedals | No - Click here to see our pedals » |
| Wheels | Merida Comp TR; 29mm inner rim width; Aluminium. Tubeless ready (tubeless tape and valves not included) |
| Front Tyre | Kenda Regolith; 29" x 2.4"; wire bead |
| Rear Tyre | Kenda Regolith; 29" x 2.4"; wire bead |
| Saddle | Merida Comp SL; V-mount |
| Seat Post | Merida Expert TR II; 34.9mm diameter; in-line; Drop: 125mm (XS), 150mm (S), 200mm (M/L/XL) |
| Discipline | MTB |
| Material | Aluminium |
| Wheel size | 29"/27.5" |
| Electric | No |
| Season | 2023 |
