The Trek Rail+ electric mountain bike is a long-travel electric enduro MTB designed for aggressive trail riding, steep alpine terrain and extended backcountry adventures. With 160 mm of front and rear suspension travel, mixed wheel sizing and up to 100 Nm of torque, the Rail+ is built to handle technical descents and sustained climbs with consistent electric support.
Engineered around Bosch’s updated Performance CX motor and a high-capacity 800 Wh PowerTube battery, the Trek Rail+ delivers powerful assistance up to 25 km/h and a ride range of approximately 4–10 hours, depending on terrain, rider input and mode selection.
Key Specifications
- Travel: 160 mm front / 160 mm rear
- Wheel size: 29″ front / 27.5″ rear (mullet setup)
- Head tube angle: 64.5°
- Motor: Bosch Performance CX
- Torque: Up to 100 Nm
- Assist: Up to 25 km/h
- Battery: 800 Wh Bosch PowerTube
- Estimated range: 4–10 hours
Bosch Performance CX Motor – Up to 100 Nm Torque
The latest Bosch Performance CX motor delivers up to 100 Nm of torque in a refined and quiet system. The high-output motor supports steep climbs, technical ascents and long-distance riding while maintaining smooth, controlled power delivery suited to enduro terrain.
800 Wh Battery with Extended Range Options
The Bosch 800 Wh PowerTube battery provides high-capacity energy storage for long mountain rides and remote trail exploration.
Additional compatibility options include:
- Bosch 600 Wh PowerTube battery for reduced overall weight
- Bosch PowerMore range extender for increased total capacity
This flexible battery platform allows riders to prioritise either extended range or lighter handling, depending on ride requirements.
Removable Integrated Battery (RIB 2.0)
The redesigned RIB 2.0 system improves battery removal and installation for charging, transport and storage. Features include:
- Secure fit designed specifically for the 800 Wh PowerTube
- Hex wrench key removal system
- Safety catch for added protection
- Improved noise reduction and battery stability
- Simplified handling when mounting to a bike rack
Refined 160 mm Suspension Platform
The Trek Rail+ features a 160 mm front and rear suspension platform engineered for aggressive trail and enduro riding.
Key suspension refinements:
- Increased anti-squat for improved pedalling efficiency on climbs
- Lower leverage rate for enhanced small-bump sensitivity
- Flip chip at the lower shock mount for a more progressive leverage curve
- Compatible with coil shocks for added end-stroke support
This configuration supports controlled descending on root networks, rock gardens and steep terrain while maintaining efficiency when climbing under motor assistance.
Adjustable Geometry and Ride Tuning
The Rail+ allows for geometry and suspension adjustments to suit different riding styles and terrain:
- Mino Link: Fine-tune bottom bracket height and adjust head tube angle by 0.5°
- Leverage rate flip chip: Increase progression for added bottom-out resistance
With a 64.5° head tube angle and mixed wheel setup, the Rail+ balances high-speed stability with responsive handling.
Integrated Bosch Control System
All Rail+ Gen 5 models feature:
- Bosch Mini Remote for intuitive assist mode changes
- Bosch System Controller for at-a-glance assist level and battery status
The integrated display and remote system are designed for streamlined cockpit control without distraction on technical trails.
The Trek Rail+ electric mountain bike is suited to riders seeking a high-powered, long-travel e-MTB capable of handling demanding descents while providing sustained electric support for extended alpine and enduro-style riding.
