Marin Rift Zone 1 2026

£1,499.00

Marin Rift Zone 1 Mountain BikeThe Marin Rift Zone 1 is the entry point into the Rift Zone family, built for riders who want a fun, capable and confidence boosting trail bike without stretching the budget. The Series 3 aluminium frame delivers 140 mm of MultiTrac LT suspension for control — Read More

GTIN (UPC): 26MARINRIFTZONE1 Categories: ,

Spread the cost from £124.92 monthly*

Buying Guides

Description

Marin Rift Zone 1 Mountain Bike

The Marin Rift Zone 1 is the entry point into the Rift Zone family, built for riders who want a fun, capable and confidence boosting trail bike without stretching the budget. The Series 3 aluminium frame delivers 140 mm of MultiTrac LT suspension for control on rough terrain, paired with a 150 mm X Fusion Sweep fork for extra support up front. A microSHIFT Advent MX 11 speed drivetrain, X Fusion Manic dropper post and Tektro hydraulic brakes create a reliable setup ready for trail centres, local loops and weekend adventures.

Key Features

  • Series 3 aluminium frame

  • 140 mm MultiTrac LT suspension

  • X Fusion Sweep 150 mm fork

  • X Fusion O2 Pro R rear shock

  • microSHIFT Advent MX 11 speed drivetrain

  • Tektro M3120 hydraulic brakes

  • Delium Rugged 29 inch tyres

  • X Fusion Manic dropper post

  • Internal cable routing

Strong And Capable Frame

The Series 3 aluminium frame uses the MultiTrac LT suspension layout for 140 mm of controlled travel. It is designed for stability on rough trails with Boost spacing, internal cable routing and a threaded bottom bracket for easy maintenance.

X Fusion Suspension

A 150 mm X Fusion Sweep fork with compression and rebound adjustment provides support and control on technical terrain. The X Fusion O2 Pro R rear shock is custom tuned for the Rift Zone platform.

Advent MX Drivetrain And Hydraulic Brakes

The microSHIFT Advent MX 11 speed drivetrain offers wide range gearing with a 11 50T cassette for steep climbs. Tektro M3120 hydraulic brakes with 180 mm rotors deliver strong and predictable stopping power.

Durable Wheels And Grippy Tyres

Marin double wall rims, forged hubs and Delium Rugged 2.4 inch tyres create a tough and grippy wheel setup. The tyres are tubeless ready for improved traction and puncture protection.

Bike specifications are advised by the manufacturer and can be subject to change without prior warning.

Please call our helpful sales team on 01539 821 443 or email us for the latest up-to-date product information.

Specification

Frame

Series 3 6N/A61 Aluminum Frame, 27.5" Wheels, 12N/Amm Travel, MultiTrac Suspension Platform, 141 Boost Spacing (upgradable to 148×12), 73mm Threaded BB w/ ISCGN/A5 Tabs

Rear Shock

X-Fusion O2 Pro R, Custom Tune, 21N/Ax5N/Amm, M8x25mm Hardware Top and Bottom

Fork

X-Fusion Slide (29) or Sweep(27.5) Boost RC, 140mm Travel, Compression and Rebound Adjustment, 44mm Offset

Head Set

FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2"

Stem

Marin 3D Forged Alloy, 35mm

Handle Bars

Marin Mini-Riser, 6N/A61 Double Butted Aluminum, 78N/Amm Width, 28mm Rise, 5 Up, 9 Back

Tape Grips

Marin MTN, Closed End

Brakes

Tektro HD-M280

Brake Levers

Tektro HD-M280

Rear Derailleur

Tektro RD-5100-L, Long Cage, Clutch

Rear Hub

Jentech D142TSE-B5, 141QR, 6-Bolt

Front Hub

Jentech D041-B15, 110x15mm, 6-Bolt

Shift Levers

Tektro, SL M5100-11R, 11-Speed

Cassette

Tektro CS-M5100-11, 11-Speed, 11-50T

Chainset

Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing

Wheels

Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible

Front Tyre

Vee Tire Snap WCE 2.35", Top 40 Compound, GXE Core, 90 TPI, Tubeless compatible

Rear Tyre

Vee Tire Snap WCE 2.35", Top 40 Compound, GXE Core, 90 TPI, Tubeless compatible

Saddle

Marin Speed Concept

Seat Post

X-Fusion Manic, 1x Composite Remote, Size XS-S 150mm Travel, Size M-XL 170mm Travel, 30.9mm

Discipline

MTB

Material

Aluminium

Wheel size

29"

Electric

No

Season

2026
