Marin TAM 1 2026

£1,899.00

Marin Tam 1 2026 Mountain BikeThe Marin Tam 1 is a fast and capable short travel trail bike built for riders who want modern geometry, efficient suspension and great value. The Series 4 aluminium frame uses 120 mm of IsoTrac flexstay suspension for smooth, controlled support on rough terrain. A — Read More

GTIN (UPC): 26MARINTAM1 Categories: ,

Spread the cost from £79.13 monthly*

Buying Guides

Description

Marin Tam 1 2026 Mountain Bike

The Marin Tam 1 is a fast and capable short travel trail bike built for riders who want modern geometry, efficient suspension and great value. The Series 4 aluminium frame uses 120 mm of IsoTrac flexstay suspension for smooth, controlled support on rough terrain. A 130 mm X Fusion Rezza fork, Advent MX 11 speed drivetrain and a Manic LC dropper post create a lightweight and responsive setup for XC loops, long days and technical singletrack. With space for two bottles, internal cable routing and easy service parts, the Tam 1 is designed for real world riding and simple maintenance.

Key Features

  • Series 4 aluminium frame

  • 120 mm IsoTrac flexstay suspension

  • X Fusion Rezza 130 mm fork

  • X Fusion Rezza rear shock

  • microSHIFT Advent MX 11 speed drivetrain

  • Tektro HD M535 hydraulic brakes

  • Delium Fast 29 inch tyres

  • X Fusion Manic LC dropper post

  • Internal cable routing

  • Room for two bottles

Lightweight And Efficient Frame

The Series 4 aluminium frame uses the IsoTrac flexstay suspension layout for 120 mm of smooth, efficient travel. It reduces weight and complexity while keeping the bike responsive on climbs and controlled on descents. The geometry uses a 65 degree head angle and 76 degree seat tube angle for stability and climbing comfort.

X Fusion Suspension

A 130 mm X Fusion Rezza fork and matching Rezza rear shock provide balanced support for XC and trail riding. The fork uses a Fine Cut damper with three position compression adjustment, while the rear shock is tuned specifically for the Tam platform.

Advent MX Drivetrain And Hydraulic Brakes

The microSHIFT Advent MX 11 speed drivetrain offers wide range gearing with a 11 50T cassette for steep climbs. Tektro HD M535 hydraulic brakes with 180 mm rotors provide consistent stopping power on long descents.

Strong Wheels And Fast Rolling Tyres

Marin double wall rims, Novatech hubs and Delium Fast 29 inch tyres create a durable and quick rolling wheel setup. The tyres are tubeless ready for improved grip and puncture protection.

Bike specifications are advised by the manufacturer and can be subject to change without prior warning.

Please call our helpful sales team on 01539 821 443 or email us for the latest up-to-date product information.

Specification

Frame

All new Series 4 Aluminum, 29" Wheels, 120mm IsoTrac Suspension Platform, Full Internal Cable Routing, Chainstay Mounted 160MM DM, 148x12mm Boost Thru-Axle, 73mm BB Shell, ISCG 05 Tabs
Rear Shock

X-Fusion Rezza, RLX 3-Pos Compression Adjust, 190x45mm, 30x8M Hardware, B-Tune
Fork

X-Fusion Rezza, 130mm Travel, Fine-Cut Damper RCP 3-Pos, 110x15mm Bolt-On Axle, 44mm Axle
Head Set

FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2"
Stem

Marin 3D Forged Alloy, 55mm
Handle Bars

Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 30mm Rise, 5 Up, 9 Back
Tape Grips

Marin Grizzly Lock-On
Brakes

Tektro HD-M535
Brake Levers

Tektro HD-M535 Hydraulic Disc
Rear Derailleur

microSHIFT Advent MX, RD-M7005M, 11-Speed
Rear Hub

Novatech, 148×12, 6-Bolt, HG Driver, 28H
Front Hub

Novatech, 110x15mm, 6-Bolt Disc, 28h
Shift Levers

microSHIFT Advent MX, SL-M7115-R, 11-Speed
Cassette

microSHIFT Advent CS-H114, 11-50T, 11-Speed
Chainset

Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, 170mm Crank Length, Boost Spacing
Wheels

Marin Aluminum Double Wall, 29mm Inner, Sleeved Joint, Disc Specific, 28H, Tubeless Compatible
Front Tyre

Maxxis Rekon Race, 29×2.35", Folding Bead, Tubeless Ready
Rear Tyre

Maxxis Rekon Race, 29×2.35", Folding Bead, Tubeless Ready
Saddle

Marin Speed Concept
Seat Post

X-Fusion Manic LC Dropper Post, Adjustable Travel, 1X Remote MMX Clamp, 30.9MM Diamter, S = 150MM / M = 170MM / L-XL = 200MM
Discipline

MTB
Material

Aluminium
Wheel size

29"
Electric

No
Season

2026
